100A RC Electric Speed Controller Brushless Motor ESC Replacement Part for DIY RC Aircraft Fixed Wing Drone

Feature: 1. High Performance 32 Bit Processor: Equipped with a high performance 32 bit processor, this brushless ESC greatly improves data processing capabilities, resulting in faster response times and smoother and more seamless startups. It also optimizes throttle linearity for more precise and stable control, delivering better compatibility. 2. Separate Control and Power Boards: The separate design of the control and power boards ensures a more aesthetically pleasing circuit layout. Even under high power conditions, the ESC heating won't directly affect the control part, increasing reliability and enhancing circuit interference resistance. 3. Multiple Protections: This ESC features multiple protections including startup protection, overheat protection, low voltage protection, phase loss protection, and signal loss protection, ensuring the safety and longevity of your aircraft. 4. LCD Programming Card Compatibility: Easily set parameters using an LCD programming card, making operation simpler and more convenient. Parameters can also be adjusted using a remote controller. 5. Regenerative Braking: With regenerative braking, the ESC significantly reduces heat generation, resulting in greater energy efficiency and longer flight time.

Specification: Item Type: RC Brushless ESC Material: Electronic component Weight: Approx. 111g/3.9oz Product Size: Approx. 90x37x10mm/3.5x1.5x0.4in Continuous Output Current: 100A Peak Output Current (Instantaneous): 120A Suitable Number of Batteries (Lithium Batteries): 2 to 6S Lipo BEC Output: 5V/6V (adjustable) 8A Parameter Programming Function: Supported Power Supply: XT60 Motor Cable: 4mm female head Signal Cable: JR head Application: RC fixed wing drone

Package List: 1 x RC Brushless ESC 1 x Specification
