Feature:
1. Design of 4?pole 12?slot high?torque motor. Full waterproof design, adapt to various environments.
2. High quality: CNC?processed 6061 T6 billet aluminum heat sink tank, high?purity copper winding can maximize efficiency, high?speed ABEC5 super large bearing.
3. Precise balanced rotor, slick, with the best reliability and the largest RPM, convenient and practical.
4. Multiple protection functions: low?voltage protection, over?temperature protection, out?of?control protection of throttle, and blocking protection.
5. Brushless motor+brushless ESC, meet your different needs, suitable for 1:8 / 1:10 RC car.
Specification:
Condition: 100% Brand New
Item Type: RC Motor ESC Set
Material: Metal + Plastic
Color: Black+Red
Quantity: 1 Set
Fitment: Fit for Traxxas
Fit for Hsp
Fit for Redcat
Fit for Tamiya
Fit for Axial scx10
Fit for Rc 4 wheel drive D90
Fit for Hpi and other brands 1:8/1:10 trucks / RC car
Motor Parameters:
KV (RPM/Volt): 4500kv
Wattage: 850
Maximum Rotating Speed: 60000
Maximum Voltage: Maximum Ampere: 100A
Number of Rotor Poles: 4
Diameter: Approx. 35.5mm / 1.4in
Length: Approx. 49mm / 1.9in
Shaft Length: Approx. 15mm / 0.6in
Connector: 4mm / 0.2in banana plug male
ESC Parameters:
Continuous Current: 60A
Burst Current: 320A
Battery: 2-3S lithium battery / 4-9S nickel-hydrogen nickel-cadmium battery
BEC Output: 6V / 1A
Motor Socket: 4mm / 0.2in female banana plug
Package List:
1 x Motor
1 x ESC
1 x Sticker
2 x Cable Tie
4 x Screw
1 x Silicone Switches Protection
2 x Silicone Tube
2 x Fixing Sticker
1 x Manual
Note:
1. Please allow slight error due to manual measurement. Thanks for your understanding.
2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
