Good luck with your favorite purchases Feature:
1.Multi switches can control different receivers. Save energy, avoid darkness.
2.Working with all kinds of Lights and Ceiling Fan, ED, CFL, Fluorescent lamp can load 300W, other can load 2500w.
3.It is a 86 wall panel that can be stuck onto anywhere. It is a learning code transmitter EV1527 IC Chip. It can be learned into most of the learning code receiver.
Specification:
controller (Receiver)
Working voltage: AC85-240V 60HZ/50HZ
Working frequency: 433MHZ
Power consumption in standby mode: <0.3W
Load power: <1100W
Receiving sensitivity: -108dBM
Working way:wireless control
Coding way: learning code
Modulation: ASK
Working temperature: -10*C~+70"C
Size: 47.4*42*22.8 (mm)
Wireless Wall Switch
Working voltage: DC3.0V
working frequency:433MHZ
Power consumption in standby mode:<1uA
Transmitter power: <10mW
Working way: wireless control
Coding way: EV1527 learning code
Modulation: ASK
Working temperature:-10"C~+70*C
Size: 86*86* 15mm
How to clear the signal
Only one step :Press the learning button(on the Receiver) 8 times. Wait for 3 seconds;
How to get the signal
Step 1: Press the learning button(on the Receiver) twice. Wait for 3 seconds;
Step 2: Press one button on the remote control. Wait for 3 seconds. Succeed.
1. Controller (receiver):
"Input voltage: 100-240V 50 / 60Hz
Maximum load current: 16A
Application Name: Mini RF433 Smart Switch
Dimensions: 42 * 42 * 20mm
Net weight: 0.031kg
Gross Weight: 0.035kg
Package size: 42*43*22mm
Outer carton size: 472*270*250mm
2.Wireless wall switch:
Wireless switch (small dot random sticker) specifications
Switch type:阪随意贴
Operating frequency:433MHZ
Battery Model:CR2032
Material:ABS+PC plastic
Code format:1527 code format
Distance:Indoor(20m),Outdoor(50m/open space)
Color: White
Size: Diameter 5cm Thickness 1.5cm
1.Controller (Receiver):
"Input Voltage: 100-240V 50 / 60Hz
Maximum load current: 16A
Application Name: Mini RF433 Smart Switch
Size: 42 * 42 * 20mm
Net weight: 0.031kg
Gross Weight: 0.035kg
Package size: 42*43*22mm
Outer carton size: 472*270*250mm
2.This product is a wireless remote control, the appearance is generous and beautiful; internal circuit design science, using SMT chip components, sound meter resonator frequency stabilization, with high stability, low power consumption and other characteristics.
Main technical indicators
Operating voltage: DC12V
Operating current: ≤12mA
Operating frequency: 315MHz, 433MHz and other frequencies can be selected.
Transmit power: ≥10mW
Transmitting distance: 30 meters (open)
Frequency deviation: ±0.2MHz
Transmission rate: 50--60KHZ
Oscillation resistance: 300K
