Blind Spot Monitoring System BSD Millimeter Wave Lane Changing Warning BSD Distance Assistant Universal for Motorcycle

Feature: 1. DUAL FUNCTIONALITY: The system combines 2 key features: Blind Spot Detection (BSD) and Lane Change Assistance (LCA). It utilizes a single 77GHz millimeter wave mounted above the rear license plate for precise target detection. 2. EFFECTIVE BLIND SPOT MONITORING: The BSD function detects vehicles within a side area of 3.5 meters by 6.5 meters. If a vehicle enters this detection zone, an alert light illuminates. If the turn signal is also activated, the alert light will flash, accompanied by an audible warning sound, enhancing driver awareness. 3. PROACTIVE LANE CHANGE ASSISTANCE: In scenarios where your vehicle is moving slowly and another vehicle is approaching at high speed, the LCA feature activates when the relative collision time is less than 3.5 seconds, ensuring that moving vehicles within 50 meters behind your car are detected, thereby preventing potential accidents during lane changes. 4. COMPREHENSIVE DETECTION RANGE: The blind spot monitoring system offers an extensive detection range: it can identify pedestrians and motorcycles within 10 15 meters, small cars (sedans) up to 15 30 meters, and larger vehicles (such as buses) within 20 50 meters, ensuring enhanced safety in various driving scenarios. 5. COMPACT AND EASY TO INSTALL: Equipped with a highly integrated chip and advanced intelligent algorithms, this system significantly reduces detection device size and installation difficulty, making it a convenient upgrade for your motorcycle. Specification: Item Type: Blind Spot Detection System with LCA Lane Change Assist Working Current: 400mA Maximum Power: 4.8W (Maximum) Working Frequency: 77GHz 78GHz Speed Range: Approx. 120km h Waterproofing Rating: IP67 Operating Temperature: 40 celsius to +85 celsius Storage Temperature: 40 celsius to +85 celsius Maximum Detection Range: Pedestrian 10 15m, Motorcycle 10 15m, Compact Car (sedan) 15 30m, Large Vehicle (buses) 20 50m BSD Alert Range: 6.5 meters to the side and rear LCA Alert Range: 50 meters Warning Method: LED flashing + audible alarm Start Up Method: Activates with ACC Package List: 1 x Sensor 1 x Buzzer 1 x Left LED Warning Light 1 x Right LED Warning Light 1 x Extension Line 4 x Wiring Harness 10 x Cable Tie 3 x Calibration Tool Note:
