Fast Charging Cable Test Module USB A to Type-C / Type-C to Type-C Cable Pin Connectivity Test Board Module With LED Indicator

Quantity : 1 High-concerned chemical : none Package : SOP Type : Module Brand Name : DIY NOW Origin : Mainland China Condition : New

Features: 1. Supports USB A to Type C and Type C to Type C cable detection, accurately locating failed pins. 2. Equipped with 12 sets of LED indicator lights to visually display the status of cable connectivity. 3. No need for external power supply, powered by CR2032 button battery, portable and easy to use. 4. Compact size, convenient for carrying and on-site testing. 5. Quickly detect full-featured Type-C cables to improve maintenance and screening efficiency. Product Introduction： This product supports USB A to Type C and Type C to Type C wire pin conductivity detection, fast charging wire test board. The product is equipped with one USB A interface and two Type C interfaces, and uses a CR2032 button battery power supply system to achieve a portable detection solution without the need for an external power supply. And the product supports full pin (24 pin) conductivity detection, accurately displaying the connectivity status of each pin through 12 independent LED indicator lights (single-sided 12 pin detection), which can quickly locate the failed pins of abnormal wires. Parameters: Color: blue Interface: TYPE-C, USB-A Power supply: CR2032 battery Product size: 50 * 30mm Instructions for Use: TYPE-C to TYPE-C： Insert the full-featured TYPE-C to TYPE-C cable into the two C ports of the module, and the indicator light will turn on, indicating that the corresponding circuit is normal. The full-featured TYPE-C cable has 24 pins, of which 22 are actually connected, so there should be 22 lights on (one side has D+D - not on). USB A to Type C Insert the USB A and TYPE-C cables into the module. Note that the TYPE-C interface cannot be inserted into the end with NC silk screen. It needs to be inserted into the USB A → TYPE C interfaces. If the indicator light is on, it means that the corresponding circuit is normal. Package Include: Wire detection module X1 label:yes
