SG600MD 120V 230V 700W Micro Solar Inverter Waterproof Grid Inverter 2.4G Communication

Feature: 1. 120V 230V waterproof micro solar inverter, LED display, more clear and intuitive. 2. 2.4G communication and monitoring method. 3. Voltage protection, frequency protection, temperature protection, current protection, etc. 4. IP65 protection grade, good dustproof and waterproof effect. 5. Natural convection cooling method, no fan. 6. Comes with a pack of screws for easier installation and saving effort. Specification: Item Type: Micro Inverter Product Series: SG series Model: SG700MD Input Data (DC, PV): Number Of Input Connectors: 2 sets MPPT Voltage Range: 24V 40V Working Voltage Range: 18V 50V Maximum Input Voltage: 50V Starting Voltage: 18V Maximum Input Power: 2 x 350W Maximum Input Current: 2 x 14A Output Data (AC): Single Phase Grid Type: 120V & 230V Rated Output Power: 650W Maximum Output Power: 700W Nominal Output Current: At 120VAC: 5A At 230VAC: 2.6A Nominal Output Voltage: 120VAC 230VAC Default Output Voltage Range: At 120VAC: 80V 160V At 230VAC: 180V 280V Nominal Output Frequency: 50Hz 60Hz Default Output Frequency Range: At 50Hz: 47.5Hz 52.5Hz At 60Hz: 57.5Hz 62.5Hz Power Factor: > 0.99 Total Harmonic Distortion: THD <5percent Maximum Units Per Branch: At 120VAC: 4 Units At 230VAC: 8 units Peak Efficiency: 95percent CEC Weighted Efficiency: At 120VAC: 92.5percent At 230VAC: 93.5percent MPPT Nominal Efficiency: 99.9percent Night Power Consumption: <700mw Working Environment Temperature Range: 40 celsius + 65 celsius Storage Temperature Range: 40 celsius + 85 celsius AC Bus Cable Maximum Current: 20A Waterproof Rating: IP65 Communication Method: 2.4G Output Connector (length cm, Left Male M, Right Female F): M24 + F182 Cooling Method: Natural convection, no fan. Package List: 1 x Inverter1 x Receiver1 Pack of Screws1 x Instruction Manual Note: Please note that the product has no adapter and needs to be wired for use.
