Feature:
1. WiFi Micro Inverter: Featuring a pure sine wave system, this 800W inverter boasts a built in MPPT for optimized energy harvesting. Built in NA integrated guard relay, practical for solar grid tie application with easy plug and play setting
2. Powerful and Practical: With powerful CPU processing capability, rich digital analog interfaces, and enhanced security, this micro inverter is suitable for digital power supplies, charging stations, energy storage inverters, and frequency converters
3. Efficient Conversion: This 800W WiFi micro inverter efficiently converts direct current (DC) to alternating current (AC) to meet grid requirements, seamlessly feeding power into the electrical grid, thereby maximizing energy utilization
4. Real Time Monitoring: Operating autonomously, this micro inverter continuously monitors PV panel performance, ensuring maximum power generation from solar modules and improving flexibility, availability, and reliability of system
5. Multiple Functions: This inverter supports battery SoC access, allows for remote start or stop, output power adjustment, zero output control, and real time data analysis, including daily and cumulative energy tracking, linkage control of other devices within the same account
Specification:
Item Type: WiFi Micro Inverter
Material: Aluminum Alloy
Application: Suitable for all kinds of household, small and medium power station intelligent energy application.
Working Mode:
1. When the inverter is working normally, the direct current generated by the photovoltaic module is converted to alternating current and supplied to the household load or fed into the public grid.
2. When the power generated by the inverter exceeds the power required by the household load, the power will be fed into the grid.
3. When the power generated by the inverter is less than the power required by the household load, it is supplemented by the grid.
Features:
Inverter screw fixing hole
Ground wire connection hole (inverter shell must be connected to ground wire)
③ Connect solar panel DC input
④ WiFi antenna
⑤ LED status indicator
⑥ Connect grid cable AC output, connect another inverter
Model: SMI800
Maximum Solar Input: 2x500W
MPPT Voltage Range (Solar Panel Open Circuit Voltage Range): 33 54V
Startup Voltage: >22V DC
Working Voltage Range: 22 60V DC
Maximum Input Current: 2x18A
Maximum Input Short Circuit Current: 2x20A
Array Maximum Feedback Current: 0A
Maximum Output Power: 800W
Rated Output Current: 3.5A
Standard Frequency Range: 50Hz
Power Factor: >0.99 default, 0.95 ing...0.95 lag
Output Current Harmonic Distortion: <5percent
Maximum Connections Per Branch: 12
Micro Inverter Peak Efficiency: 92.70percent
CEC Weighted Efficiency: 92.50percent
Nominal MPPT Efficiency: 99.80percent
Night Power Consumption (mW) : 0
Ambient Temperature Range: 20 50 celsius
Storage Temperature Range: 20 50 celsius
Product Size (L x W x H): Approx. 284 x 200 x 49mm 11.2 x 7.9 x 1.9in
Water Proof Rating: Outdoor Nema 3r (IP67)
Cooling Mode: Naturally Cooling (no fan)
Pollution Level: PD3
Power Transfer Mode: Reverse transmfer, load first
Communicating Method: WiFi
Rated Transmitting Power:
802.11b: +17dBm + 1.5dBm (at 11Mbps)
802.11g: +15dBm + 1.5dBm (at 54Mbps)
802.11n: +14dBm + 1.5dBm (at HT20, MCS7)
Monitoring System: For Smart Life
BT: 2402 2480MHz BT EIRP Power (Maximum) 7.89dBm
Wireless Transfer (2.4G) : 2412 2472MHz Wifi 2.4G EIRP Power (Maximum) 18.08dBm
Weight: Approx. 4200g 148.2oz.
Package List:
1 x WiFi Micro Inverter
1 x 5M Power Cord
2 x Screws
2 x Washers
2 x Accessory Rings
2 x Nuts
2 x User Manuals
1 x Accessory
Note:
Please install the inverter and all DC connectors below the PV modules to avoid rain, snow, light exposure, and direct sunlight. Leave at least 5 cm space around the micro inverter casing to ensure ventilation and heat dissipation. Local grid regulations may apply for some countries.
